Airveda Thermo

Meet India’s most ACCURATE and APP-ENABLED, monitor for measuring Temperature, humidity concentration in real-time.


Airveda PM2.5, PM10, and Temperature, Humidity, Wind Speed, Wind Direction, Light and Noise Monitor
Airveda PM2.5, PM10, and Temperature, Humidity, Wind Speed, Wind Direction, Light and Noise Monitor
airveda-eye
airveda-eye
airveda-eye

Options

airveda-sky-black

2 Line LCD Display

airveda-sky-white

No Display

Accurate

Airveda Thermo Monitor uses High-quality laser sensors, calibrated for Indian conditions against a BAM (Beta Attenuation Monitor- the most advanced system for measuring ambient air quality)


Made In India - Locally Manufactured & Serviced

Airveda monitors are completely manufactured and serviced in India. Sensors are also calibrated locally to suit Indian conditions. Our manufacturing facility has been running for 30 years and is a trusted name in the local industry.


Portable & Real Time

The small size and long battery life of 4-6 hours make the monitor extremely portable. Can be charged using any USB power outlet in your car, laptop, or power bank. Air quality is measured every second to provide real-time data.


Mobile App Enabled

Real-time and historic data and alerts can be viewed in the Airveda app, available on iOS and Android.


Dashboard & T.V. Displays

Our state of the art Dashboards provide complete analytics, alerts, ability to download data, see trends and understand performance wrt standards. TV displays provide flexible templates which can be customized easily to show data to occupants on TVs. These features require purchase of our Data plan. Please talk to our team if interested to learn more.


Display:
2 Line LCD Display
No Display

Model Number: AVTH-2L-MB

PRODUCT DETAILS

Technical Specifications

  • Parameter
    • Measurement parameters: Temperature, Humidity
    • Temperature
      • Range: 0-60 deg C
      • Resolution: 0.1 deg C
      • Error: 1 deg C
      • Warm up time: 0 deg C
      • Working Principle: CMOS
      • Life of sensor: ≥10 years
      • Calibration: Can be calibrated using the mobile app in configuration mode. Under Advanced Settings.
    • Humidity
      • Range: 0-90%
      • Resolution: 1%
      • Error: 3%
      • Warm up time: 0%
      • Working Principle: CMOS
      • Life of sensor: ≥10 years
      • Calibration: Can be calibrated using the mobile app in configuration mode. Under Advanced Settings.
  • Display
    • 2 Line Display
    • No Display
  • Power
    • Charger Input:
      • Input AC: 110-240V, 0.3A, 50-60Hz 5V/2A (Charger)
    • Charger Output:
      • Output DC: 5V-2A (max) connected to the device via micro USB socket
    • Power Consumption: 10 Watt (Peak Power)
    • Internal Battery: 2900mAH/3.7V Lithium-ion rechargeable battery
    • Battery Backup: 4-6 Hours
  • Dimensions
    • Front:
      • Width: 117 mm
      • Height: 117 mm
      • Protrusion: 2 mm
      • Height (total): 119 mm
    • Back:
      • Width: 120 mm
      • Height: 120 mm
      • Protrusion: 2 mm
      • Height (total): 122 mm
    • Depth: 50mm + 1~1.5 mm (polyester plate)
    • Protrusion location: 38mm from back of device
  • Weight: 370 grams
  • MATERIAL: ABS
  • IP RATING: IP51
  • Operating Temperature: 0-60 degC
  • Operating Humidity: 0-95%

Service Contract

  • 1 Year warranty against any manufacturing defects.
  • Client responsible for getting devices to our facilities for all servicing. Service time 7-10 working days.
  • Warranty is void if the device is opened, tampered with or electronics damaged due to mechanical shock.
  • Warranty does not include sensor change.

APP CONFIGURABLE FEATURES

Note: After making changes to the app, the device must be turned off and on once, and connected to the internet to receive updated settings from the server.
  • Measurement Frequency
    • Default
      • Cloud Storage: Data is measured every 30 seconds (measurement frequency) and sent to the server every 1 minute (Sending Frequency).
    • Configurable Measurement frequency
      • Can be changed to 30 sec,1min, 5min, 10min, and 20min via mobile app.
    • Configurable Sending frequency
      • Can be changed to 30 sec,1min, 5min, 10min, and 20min via mobile app.
    • Note:
      • Longer sending frequency reduces power usage and battery backup as sending data to the server is very battery intensive.
      • Longer measurement frequency ensures longer local memory as a fixed number of items are stored in the memory. Also, the sensor is turned off in between intervals which may help extend sensor life.
  • Alert Limits and Traffic Light Signal
    • Alert limits can be configured for each parameter via the app.
    • Get notifications on the app when alert limits are exceeded
    • The colour of the LED on the device will show green if all parameters are within the limit and yellow and red if any parameter exceeds set limits.
  • Display Settings
    • Night mode in the app enables the device display to turn off at night. (Night hours configurable).
    • Get notifications on the app when alert limits are exceeded
    • Display brightness setting allows you to configure brightness when connected to power, on battery and in power saver mode. This enables energy savings as well as extending the life of the battery.
  • Communication
    • Wi-Fi
      • Supports configuring up to 5 Wi-Fi networks including your home, office, or personal hotspot.
      • Device will automatically connect with the Wi-Fi when it becomes available.
    • MODBUS RS485
      • Modbus ID, parity, stopbits, and baudrate configurable via the Airveda app during configuration. Available under Advanced Settings.
      • Up to 32 devices can be connected in a single loop without using repeaters under ideal conditions.
      • Audio jack socket provided on the device.
      • Data will start transmitting after 20 seconds, once data stabilizes. Exception response 05
  • Local Memory
    • 7000 time-stamped sample data sets can be saved in case of connectivity failure. Local memory stores data for 2 days to 40 days based on the measurement frequency.
  • Data Interval
    • 30 Seconds to 20 min (Configurable via app)
  • Data push protocol
    • HTTP post request to host-server
